IGBT Inverter DC TIG / MMA Welding Machine - Three Phase

Integrated System Savings

Simpler installation when all systems are wired to one central box (the iCNC) and can be pre-set to work with each other.
Less case by case engineering.
No finger pointing from vendor to vendor.
Remote one spot access to the whole system and a possibility to do joined remote sessions with Thermal Dynamics specialists for help and training.
All information is available in one location and all settings and tuning can be done on the same screen.

Specification

MODEL	WS-250D	WS-315D	WS-400D	WS-500D
Input Voltage	3 x 380V/400/415V, 50/60HZ
Input Power Capacity	9KVA	12KVA	16KVA	25KVA
No Load Voltage	65-75V
Current Range	20-250A	20-315A	20-400A	50-500A
Rate Duty Cycle	60%
Current Down Slope Time	0-10 S
Gas Post Flow	1-25 S
Dimentions (L X W X H)	520 x 305 x 540mm
Weight (Kg)	30	37	40	48
